Hangzhou Ocean Industry Co., Ltd. yog ib qho ntawm cov ua lag luam thiab cov neeg muag khoom ntawm helical iav khib hauv Suav teb. Txais tos rau cov lag luam wholesale bulk check industrial chains thiab fais fab kis qhov chaw ua nyob rau hauv Suav teb nov los ntawm peb lub hoobkas. Tag nrho cov khoom customized yog nrog cov khoom zoo thiab cov nqi sib tw.
Feem ntau ntawm Dej Hiav Txwv Helical Gear Rack raug xa tawm mus rau Tebchaws Europe txij li xyoo 2005. Feem ntau ntawm Ocean OEM cov neeg siv khoom xa cov duab kos thiab dej hiav txwv tsim raws li lawv cov duab kos, yog tias koj tsis muaj duab kos, Dej hiav txwv kuj tuaj yeem tsim raws li koj tus qauv.
Parameter
| Code | Module | Cov hniav | L | L1 | No. Cov hniav | A | B | h0 | C1 | C2 | C3 | C4 | No.of Holes | h | D1 | D2 | T | D3 | Kg |
| M1 15X15X500 | 1 | 3.3333 | 500 | 5.32 | 150 | 15 | 15 | 14 | 31.7 | 436.6 | 62.5 | 25 | 4 | 6 | 5 | 8 | 5 | 5.7 | 0.8 |
| M1 15X15X1000 | 1 | 3.3333 | 1000 | 5.32 | 300 | 15 | 15 | 14 | 31.7 | 936.6 | 62.5 | 25 | 8 | 6 | 5 | 8 | 5 | 5.7 | 1.6 |
| M2 25X24X500 | 2 | 6.6667 | 500 | 8.36 | 75 | 25 | 24 | 22 | 31.7 | 436.6 | 62.5 | 125 | 4 | 8 | 7 | 11 | 7 | 5.7 | 2.1 |
| M2 25X24X1000 | 2 | 6.6667 | 1000 | 8.86 | 150 | 25 | 24 | 22 | 31.7 | 936.6 | 62.5 | 125 | 8 | 8 | 7 | 11 | 7 | 5.7 | 4.3 |
| M2 25X24X2000 | 2 | 6.6667 | 2000 | 8.86 | 300 | 25 | 24 | 2 | 31.7 | 936.6 | 62.5 | 125 | 16 | 8 | 7 | 11 | 7 | 5.7 | 8.6 |
| M3 30X29X500 | 3 | 10.0000 | 500 | 10.64 | 50 | 30 | 29 | 26 | 35 | 430 | 62.5 | 125 | 4 | 9 | 0 | 15 | 9 | 7.7 | 3.1 |
| M3 30X29X1000 | 3 | 10.0000 | 1000 | 10.64 | 100 | 30 | 29 | 26 | 35 | 930 | 62.5 | 125 | 8 | 9 | 0 | 15 | 9 | 7.7 | 6.2 |
| M4 30X29X2000 | 4 | 10.0000 | 2000 | 10.64 | 200 | 30 | 29 | 26 | 35 | 1930 | 62.5 | 125 | 16 | 9 | 10 | 15 | 9 | 7.7 | 12.5 |
| M4 40X39X507 | 4 | 13.3333 | 506.6 | 14.18 | 38 | 40 | 39 | 35 | 33.3 | 440 | 65.8 | 125 | 4 | 12 | 10 | 15 | 9 | 7.7 | 5.5 |
| M4 40X39X1000 | 4 | 13.3333 | 1000 | 14.18 | 75 | 40 | 39 | 35 | 33.3 | 933.4 | 62.5 | 125 | 8 | 12 | 10 | 15 | 9 | 7.7 | 10.9 |
| M4 40X39X2000 | 4 | 13.3333 | 2000 | 14.18 | 150 | 40 | 39 | 35 | 33.3 | 1933.4 | 62.5 | 125 | 16 | 12 | 10 | 15 | 9 | 7.7 | 21.8 |
| M5 50X39X1000 | 5 | 16.6667 | 1000 | 17.73 | 60 | 50 | 39 | 34 | 37.5 | 925 | 62.5 | 125 | 8 | 12 | 14 | 20 | 13 | 11.7 | 13 |
| M5 50X39X2000 | 5 | 16.6667 | 2000 | 17.73 | 120 | 50 | 39 | 34 | 37.5 | 1925 | 62.5 | 125 | 16 | 12 | 14 | 20 | 13 | 11.7 | 26 |
| M6 60X49X1000 | 6 | 20.0000 | 1000 | 21.28 | 50 | 60 | 49 | 43 | 37.5 | 925 | 62.5 | 125 | 8 | 16 | 18 | 26 | 17 | 15.7 | 19.8 |
| M6 60X49X2000 | 6 | 20.0000 | 2000 | 21.28 | 100 | 60 | 49 | 43 | 37.5 | 1925 | 62.5 | 125 | 16 | 16 | 18 | 26 | 17 | 15.7 | 39.6 |
| M8 80X79X960 | 8 | 26.6667 | 960 | 28.37 | 36 | 80 | 79 | 71 | 120 | 720 | 60 | 120 | 8 | 25 | 18 | 33 | 21 | 19.7 | 42.5 |
| M8 80X79X1920 | 8 | 26.6667 | 1920 | 28.37 | 72 | 80 | 79 | 71 | 120 | 1680 | 60 | 120 | 16 | 25 | 18 | 33 | 21 | 19.7 | 85 |
| M10 100X99X1000 | 10 | 33.3334 | 1000 | 35.46 | 30 | 100 | 99 | 89 | 125 | 750 | 62.5 | 125 | 8 | 32 | 33 | 48 | 32 | 19.7 | 68.7 |
| M10 100X99X2000 | 10 | 33.3334 | 2000 | 35.46 | 60 | 100 | 99 | 89 | 125 | 1750 | 62.5 | 125 | 16 | 32 | 33 | 48 | 32 | 19.7 | 137.4 |
| M12 120X120X1000 | 12 | 40 | 1000 | 42.56 | 25 | 120 | 120 | 108 | 125 | 750 | 62.5 | 125 | 8 | 40 | 39 | 58 | 38 | 19.7 | 120 |
| M12 120X120X2000 | 12 | 40 | 2000 | 42.56 | 50 | 120 | 120 | 108 | 125 | 1750 | 62.5 | 125 | 16 | 60 | 39 | 58 | 38 | 19.7 | 240 |
