Name: Tuam Tshoj Customized High Strength Short Pitch Roller Chains Chaw tsim tshuaj paus Hoobkas - Dej hiav txwv
Brand: Dej hiav txwv
SKU: 315692591

Hangzhou Dej hiav txwv kev lag luam Co., Ltd. yog ib qho ntawm cov ua lag luam thiab cov neeg muag khoom ntawm lub zog siab luv pitch roller chains hauv Suav teb. Txais tos rau cov lag luam wholesale bulk check industrial chains thiab fais fab kis qhov chaw ua nyob rau hauv Suav teb nov los ntawm peb lub hoobkas. Tag nrho cov khoom customized yog nrog cov khoom zoo thiab cov nqi sib tw.

Hangzhou Ocean Industry Co., Ltd. yog cov chaw tsim khoom thiab feem ntau ntawm peb cov khoom raug xa tawm mus rau Tebchaws Europe txij li xyoo 2005.

Peb cov kev txuas tshwj xeeb thiab cov saw hlau ua liaj ua teb haum rau txhua qhov kev ua haujlwm hnyav. Lawv yog ua los ntawm cov hlau resistant alloysteel nrog anti-corrosioncoating thiab yog sib xws nrog kev cai K, F, CA attachments rau sau, tsheb laij teb thiab balers.High tensile zog rau lub neej kev pab cuam ntev, saj zawg zog OEM & ODM rau ntiaj teb no ua liaj ua teb machinery wholesalers.

Parameter

Feem ntau ntawm peb cov neeg siv khoom OEM xa peb daim duab thiab peb yuav tsim raws li lawv daim duab. Koj tuaj yeem xa peb cov duab kos los ntawm e-mail thiab ces peb tus engineer yuav muab kev pab. Yog tsis muaj duab kos, qauv kuj OK. Catalog kuj OK.

Drawings thiab cov ntaub ntawv parameter

High-lub zog rau cov menyuam saws tau raws li ISO, DIN, ANSI thiab lwm yam qauv, feem ntau suav nrog SP series siab -lub zog luv- suab cov menyuam chains, SH series siab-lub zog luv-pitchheavy-lub luag haujlwm rau cov menyuam chains thiab DH-}X3 series.

Nrog lub duav dav tsim, siab - cov ntaub ntawv zoo thiab thev naus laus zis nrog kev ywj pheej ntawm kev txawj ntse txoj cai, lub zog tensile ncav cuag ntau tshaj 1.2 npaug ntawm qhov tsawg kawg nkaus tensile lub zog ntawm ISO tus qauv, DH-X3 series cov khoom muaj.High saw length raug: mus txog 2/3 ntawm ISO standard chain length accuracy.High fatigue zog: mus txog lub zog ntawm ISOH 1. mus rau 2 npaug ntawm kev hnav tsis kam ntawm cov txheej txheem cov saw hlau.

Cov khoom siv dav siv hauv ntau yam felds xws li kev tsim kho tshuab, tshuab ua liaj ua teb, kev thauj mus los thiab kev thauj mus los, thiab xa hluav taws xob rau ntau lub tshuab thiab chaw, xws li balers. rotary tillers, skid loaders, thiab lwm yam.

SP series siab lub zog luv luv pitch roller chains

Simplex, Duplex & Triplex strands

Los ntawm kev siv qhov zoo tshaj plaws tsim ntawm cov qauv qhov ntev, cov khoom siv thiab cov txheej txheem kho cua sov, lub zog tensile ntawm SP series siab zog cov menyuam saw yog 28% ntau dua li ntawm A series txheem cov menyuam saw. Ntxiv mus, nws muaj kev ua tau zoo heev ntawm qaug zog lub zog thiab cuam tshuam tsis kam thiab lwm yam.

1 SP series high strength short pitch roller chains

Chain No.	Suab	Cov menyuam txoj kab uas hla	Dav nruab nrab daim hlau sab hauv	Pin txoj kab uas hla	Pin ntev		Sab hauv phaj qhov tob	Phaj tuab	Hloov suab	Tensile zog	Nruab nrab tensile zog	Qhov hnyav rau meter
	P	d1 max	b1 min	d2 max	L max	Lc max	h2 max	T	Pt	Q min	Q0	q
	mm	mm	mm	mm	mm	mm	mm	mm	mm	kN/lbf ib	kN kev	kg/m
80 NP-1	25.40	15.88	15.75	7.94	32.7	36.5	24.1	3.2	-	77.5/17434	85.3	2.86
100 SP-1	31.75	19.05	18.95	9.54	40.4	44.7	30.1	4.0	-	115.5/25982	127.0	4.21
120 SP-1	38.10	22.23	25.22	11.11	50.3	54.3	36.2	4.8	-	165.0/37118	186.0	6.36
140 NP-1	44.45	25.40	25.22	12.71	54.4	59.0	42.2	5.6	-	222.7/50098	245.0	8.04
160 NP-1	50.80	28.58	31.55	14.29	64.8	69.6	48.2	6.4	-	285.5/64215	314.0	10.80
200 SP-1	63.50	39.68	37.85	19.85	80.3	87.2	60.3	8.0	-	445.5/100208	490.0	18.00
80 NP-2	25.40	15.88	15.75	7.94	62.7	65.8	24.1	3.2	29.29	155.0/34868	170.6	5.68
100 SP-2	31.75	19.05	18.95	9.54	76.4	80.5	30.1	4.0	35.76	231.0/51965	255.0	8.34
120 SP-2	38.10	22.23	25.22	11.11	95.8	99.7	36.2	4.8	45.44	339.0/76260	373.0	12.63
140 NP-2	44.45	25.40	25.22	12.71	103.3	107.9	42.2	5.6	48.87	445.5/100218	490.0	15.92
160 NP-2	50.80	28.58	31.55	14.29	123.3	128.1	48.2	6.4	58.55	571.0/128430	628.0	21.43
200 SP-2	63.50	39.68	37.85	19.85	151.9	158.8	60.3	8.0	71.55	892.0/200621	981.0	35.00
80 NP-3	25.40	15.88	15.75	7.94	91.7	95.1	24.1	3.2	29.29	232.5/52302	255.9	8.18
100 SP-3	31.75	19.05	18.95	9.54	112.2	116.3	30.1	4.0	35.76	347.3/78128	382.0	12.47
120 SP-3	38.10	22.23	25.22	11.11	141.4	145.2	36.2	4.8	45.44	508.0/114278	559.0	18.90
140 ZPO-3	44.45	25.40	25.22	12.71	152.2	156.8	42.2	5.6	48.87	668.0/150271	735.0	23.84
160 NP-3	50.80	28.58	31.55	14.29	181.8	186.6	48.2	6.4	58.55	855.5/192441	941.0	32.10
200 SP-3	63.50	39.68	37.85	19.85	223.5	230.4	60.3	8.0	71.55	1336.4/300633	1470.0	52.50

Simplex, Duplex & Triplex strands

2 SP series high strength short pitch roller chains

Chain No.	Suab	Cov menyuam txoj kab uas hla	Dav nruab nrab daim hlau sab hauv	Pin txoj kab uas hla	Pin ntev		Sab hauv phaj qhov tob	Phaj tuab	Hloov suab	Tensile zog	Nruab nrab tensile zog	Qhov hnyav rau meter
	P	d1 max	b1 min	d2 max	L max	Lc max	h2 max	T	Pt	Q min	Q0	q
	mm	mm	mm	mm	mm	mm	mm	mm	mm	kN/lbf ib	kN kev	kg/m
80 HSP-1	25.40	15.88	15.75	7.94	36.2	38.9	24.1	4.0	-	89.2/20066	98.1	3.36
100 HSP-1	31.75	19.05	18.95	9.54	43.6	46.9	30.1	4.8	-	131.8/29649	145.0	4.90
120 HSP-1	38.10	22.23	25.22	11.11	53.5	57.5	36.2	5.6	-	176.0/39592	196.0	7.12
140 HSP-1	44.45	25.40	25.22	12.71	57.6	62.2	42.2	6.4	-	231.9/52149	255.0	8.88
160 HSP-1	50.80	28.58	31.55	14.29	68.2	73.0	48.2	7.2	-	294.5/66260	324.0	11.72
200 HSP-1	63.50	39.68	37.85	19.85	86.6	93.5	60.3	9.5	-	543.6/122295	598.0	19.80
80 HSP-2	25.40	15.88	15.75	7.94	68.8	72.0	24.1	4.0	32.59	178.4/40132	196.2	6.65
100 HSP-2	31.75	19.05	18.95	9.54	82.7	86.0	30.1	4.8	39.09	263.6/59299	290.0	9.71
120 HSP-2	38.10	22.23	25.22	11.11	102.4	106.4	36.2	5.6	48.87	356.4/80175	392.0	14.12
140 HSP-2	44.45	25.40	25.22	12.71	109.8	114.4	42.2	6.4	52.20	463.6/104300	510.0	17.38
160 HSP-2	50.80	28.58	31.55	14.29	130.1	134.9	48.2	7.2	61.90	588.0/132275	647.0	23.00
200 HSP-2	63.50	39.68	37.85	19.85	164.9	171.8	60.3	9.5	78.31	1091.0/245429	1200.0	38.50
80 HSP-3	25.40	15.88	15.75	7.94	101.4	104.6	24.1	4.0	32.59	267.6/60200	294.3	9.95
100 HSP-3	31.75	19.05	18.95	9.54	121.8	125.1	30.1	4.8	39.09	395.4/88948	435.0	14.53
120 HSP-3	38.10	22.23	25.22	11.11	151.2	155.2	36.2	5.6	48.87	534.5/120250	588.0	21.12
140 HSP-3	44.45	25.40	25.22	12.71	162.0	166.6	42.2	6.4	52.20	695.5/156448	765.0	25.88
160 HSP-3	50.80	28.58	31.55	14.29	192.0	196.8	48.2	7.2	61.90	882.7/198576	971.0	34.22
200 HSP-3	63.50	39.68	37.85	19.85	243.2	250.1	60.3	9.5	78.31	1627.3/366073	1790.0	57.29

Duplex roller chains

3 SP series high strength short pitch roller chains

Chain No.	Suab	Cov menyuam txoj kab uas hla	Dav nruab nrab daim hlau sab hauv	Pin txoj kab uas hla	Pin ntev		Sab hauv phaj qhov tob	Phaj tuab	Hloov suab	Tensile zog	Nruab nrab tensile zog	Qhov hnyav rau meter
	P	d1 max	b1 min	d2 max	L max	Lc max	h2 max	T	Pt	Q min	Q0	q
	mm	mm	mm	mm	mm	mm	mm	mm	mm	kN/lbf ib	kN kev	kg/m
80 HSP-1	25.40	15.88	15.75	7.94	36.2	38.9	24.1	4.0	-	89.2/20066	98.1	3.36
100 HSP-1	31.75	19.05	18.95	9.54	43.6	46.9	30.1	4.8	-	131.8/29649	145.0	4.90
120 HSP-1	38.10	22.23	25.22	11.11	53.5	57.5	36.2	5.6	-	176.0/39592	196.0	7.12
140 HSP-1	44.45	25.40	25.22	12.71	57.6	62.2	42.2	6.4	-	231.9/52149	255.0	8.88
160 HSP-1	50.80	28.58	31.55	14.29	68.2	73.0	48.2	7.2	-	294.5/66260	324.0	11.72
200 HSP-1	63.50	39.68	37.85	19.85	86.6	93.5	60.3	9.5	-	543.6/122295	598.0	19.80
80 HSP-2	25.40	15.88	15.75	7.94	68.8	72.0	24.1	4.0	32.59	178.4/40132	196.2	6.65
100 HSP-2	31.75	19.05	18.95	9.54	82.7	86.0	30.1	4.8	39.09	263.6/59299	290.0	9.71
120 HSP-2	38.10	22.23	25.22	11.11	102.4	106.4	36.2	5.6	48.87	356.4/80175	392.0	14.12
140 HSP-2	44.45	25.40	25.22	12.71	109.8	114.4	42.2	6.4	52.20	463.6/104300	510.0	17.38
160 HSP-2	50.80	28.58	31.55	14.29	130.1	134.9	48.2	7.2	61.90	588.0/132275	647.0	23.00
200 HSP-2	63.50	39.68	37.85	19.85	164.9	171.8	60.3	9.5	78.31	1091.0/245429	1200.0	38.50
80 HSP-3	25.40	15.88	15.75	7.94	101.4	104.6	24.1	4.0	32.59	267.6/60200	294.3	9.95
100 HSP-3	31.75	19.05	18.95	9.54	121.8	125.1	30.1	4.8	39.09	395.4/88948	435.0	14.53
120 HSP-3	38.10	22.23	25.22	11.11	151.2	155.2	36.2	5.6	48.87	534.5/120250	588.0	21.12
140 HSP-3	44.45	25.40	25.22	12.71	162.0	166.6	42.2	6.4	52.20	695.5/156448	765.0	25.88
160 HSP-3	50.80	28.58	31.55	14.29	192.0	196.8	48.2	7.2	61.90	882.7/198576	971.0	34.22
200 HSP-3	63.50	39.68	37.85	19.85	243.2	250.1	60.3	9.5	78.31	1627.3/366073	1790.0	57.29

Duplex roller chains

4 SH series high strength short pitch roller chains

Chain No.	Suab	Cov menyuam txoj kab uas hla	Dav nruab nrab daim hlau sab hauv	Pin txoj kab uas hla	Pin ntev		Sab hauv phaj qhov tob	Phaj tuab	Tensile zog	Nruab nrab tensile zog	Qhov hnyav rau meter
	P	d1 max	b1 min	d2 max	L max	Lc max	h2 max	t/T	Q min	Q0	q
	mm	mm	mm	mm	mm	mm	mm	mm	kN/lbf ib	kN kev	kg/m
* 25 SH	6.350	3.30	3.18	2.31	9.0	-	6.00	1.04	5.09/1157	5.6	0.11
* 35 SH	9.525	5.08	4.77	3.58	13.3	14.3	9.00	1.50	11.00/2500	13.6	0.41
40 SH	12.700	7.95	7.85	3.96	18.8	19.9	12.00	2.03	22.40/5091	24.8	0.82
50 SHJ	15.875	10.16	9.40	5.08	22.1	23.4	15.09	2.42	30.40/6909	36.2	1.25
60 SHJ	19.050	11.91	12.57	5.94	29.2	31.6	18.00	3.25	44.10/10023	50.4	1.87
#5H63	19.050	14.29	9.55	7.30	27.9	-	19.60	4.15/3.25	65.70/14932	73.0	2.62
60 TXF 1	19.050	11.91	9.50	5.94	25.4	27.6	18.00	3.25	44.10/9914	48.5	1.77
#C60SHF2	19.050	12.70	11.10	7.11	29.3	-	18.90	4.0/3.25	61.80/13893	68.0	2.47
#C70SH	22.225	15.60	14.30	7.94	36.6	-	22.60	4.8/4.0	88.25/20056	98.0	3.75
#C70SHF1	22.225	15.60	14.30	7.93	35.8	-	23.50	4.8/4.0	81.40/18299	89.5	3.76
80SH ua	25.400	15.88	15.75	7.92	36.2	37.7	24.00	4.00	88.20/20045	93.0	3.10
955	28.575	21.30	17.46	11.10	46.8	-	30.60	6.4/5.6	142.10/35635	156.8	7.95
100 SH	31.750	19.05	18.90	9.53	43.6	46.9	30.00	4.80	116.60/26500	129.1	4.52
120 SWB	38.100	22.23	25.22	11.10	53.5	57.5	35.70	5.60	158.20/35954	175.3	6.60
140 SWB	44.450	25.40	25.22	12.70	57.6	62.2	41.00	6.40	206.00/46818	266.5	8.30
160 SWB	50.800	28.58	31.55	14.27	68.2	73.0	47.80	7.20	274.00/62273	293.0	10.30
180 SWB	57.150	35.71	35.48	17.46	75.9	81.6	53.60	8.00	337.20/75803	370.9	14.83
200 SH	63.500	39.68	37.85	19.85	86.6	93.5	60.00	9.50	506.10/115023	562.3	19.16
240 SWB	76.200	47.63	47.35	23.81	109.6	115.9	72.30	12.70	650.00/146120	715.0	30.40
* Bush saw: d1 nyob rau hauv lub rooj qhia txog sab nraud txoj kab uas hla ntawm hav txwv yeem.
# Daim phiaj ncaj ncaj

X3 series kev ua haujlwm siab rau cov menyuam chains

X 3® series kev ua haujlwm siab rau cov menyuam saw yog ua raws li kev tsim kho kom zoo, kev siv thev naus laus zis thiab kev tswj hwm zoo, kev qaug zog yog 60 feem pua ntau dua li ISO 606 tus qauv rau cov menyuam saw ntawm tib lub ntsiab lus, thiab hnav resistant yog nce.

5 X3 series high performance roller chains

Chain No.	Suab	Cov menyuam txoj kab uas hla	Dav nruab nrab daim hlau sab hauv	Pin txoj kab uas hla	Pin ntev		Sab hauv phaj qhov tob	Phaj tuab	Hloov suab	Tensile zog	Nruab nrab tensile zog	Qhov hnyav rau meter
	P	d1 max	b1 min	d max	L max	Lc max	h2 max	t/T	Pt	Q min	Q0	q
	mm	mm	mm	mm	mm	mm	mm	mm	mm	kN/lbf ib	kN kev	kg/m
*06BX3-1	9.525	6.35	5.72	3.28	13.15	14.10	8.20	1.30	-	10.0/2248	11.00	0.43
08 TX3-1	12.700	8.51	7.75	4.45	16.70	18.20	11.80	1.60	-	21.0/4721	23.10	0.74
10 TX3-1	15.875	10.16	9.65	5.08	19.50	20.90	14.70	1.70	-	28.5/6407	31.35	1.00
12 TX3-1	19.050	12.07	11.68	5.72	22.50	24.20	16.00	1.85	-	33.0/7418	36.30	1.23
16 TX3-1	25.400	15.88	17.02	8.28	36.10	37.40	21.00	4.15/3.10	-	70.0/15736	77.00	2.90
20 TX3-1	31.750	19.05	19.56	10.19	41.30	45.00	26.50	4.50/3.50	-	106.7/23986	117.37	3.96
24 TX3-1	38.100	25.40	25.40	14.63	53.40	57.80	33.20	6.00/4.80	-	176.0/39565	193.60	7.60
28 TX3-1	44.450	27.94	30.99	15.90	65.10	69.50	36.70	7.50/6.00	-	230.0/51704	253.00	9.10
32 TX3-1	50.800	29.21	30.99	17.81	66.00	71.00	42.00	7.00/6.00	-	280.0/62944	308.00	10.97
06 TX3-2	9.525	6.35	5.72	3.28	23.40	24.40	8.20	1.30	10.24	18.5/4159	20.35	0.82
08 TX3-2	12.700	8.51	7.75	4.45	31.00	32.20	11.80	1.60	13.92	36.0/8093	39.60	1.43
10 TX3-2	15.875	10.16	9.65	5.08	36.10	37.50	14.70	1.70	16.59	55.6/12499	61.16	1.97
12 TX3-2	19.050	12.07	11.68	5.72	42.00	43.60	16.00	1.85	19.46	63.5/14275	69.85	2.47
16 TX3-2	25.400	15.88	17.02	8.28	68.00	69.30	21.00	4.15/3.10	31.88	121.9/27403	134.09	5.80
20 TX3-2	31.750	19.05	19.56	10.19	7.80	81.50	26.50	4.50/3.50	36.45	211.2/47478	232.32	7.70
24 TX3-2	38.100	25.40	25.40	14.63	101.70	106.20	33.20	6.00/480	48.36	308.0/69238	338.80	14.34
28 TX3-2	44.450	27.94	30.99	15.90	124.60	129.10	36.70	7.50/6.00	59.56	414.0/93067	455.40	17.76
32 TX3-2	50.800	29.21	30.99	17.81	124.60	129.60	42.00	7.00/6.00	58.55	504.0/113299	554.40	22.47
* Cov phaj ncaj ncaj

FAQ

Q: Dab tsi daim ntawv thov yuav tsum muaj lub zog siab luv luv pitch roller chains?
A: Heavy - lub luag haujlwm tshuab nrog kev ua haujlwm siab siab - thauj khoom xa mus.

Q: Cov saw hlau puas yuav nthuav dav tom qab ntev ntev -load khiav?
A: Tsawg elongation tsim kom ruaj khov kis tau tus mob.

Q: Yog tias koj tsis tuaj yeem pom cov khoom ntawm peb lub vev xaib, koj yuav ua li cas ntxiv?

A: Thov xa peb cov lus nug nrog cov khoom duab thiab kos duab los ntawm email lossis lwm txoj hauv kev thiab peb yuav kuaj.

Q: Koj lub sijhawm xa khoom thiab xa khoom ntev npaum li cas?

A: 1.Sample Lead-times: feem ntau 10 hnub ua haujlwm.

2.Production Lead-times: 20-40 hnub ua haujlwm tom qab tau txais koj cov nyiaj tso cia.
