Hangzhou Dej hiav txwv kev lag luam Co., Ltd. yog ib qho ntawm cov tuam txhab ua lag luam thiab cov chaw muag khoom ntawm cov kab ntau lawm conveyor chains hauv Suav teb. Txais tos rau cov lag luam wholesale bulk check industrial chains thiab fais fab kis qhov chaw ua nyob rau hauv Suav teb nov los ntawm peb lub hoobkas. Tag nrho cov khoom customized yog nrog cov khoom zoo thiab cov nqi sib tw.
Hangzhou Ocean Industry Co., Ltd. yog cov chaw tsim khoom thiab feem ntau ntawm peb cov khoom raug xa tawm mus rau Tebchaws Europe txij li xyoo 2005.
Peb cov kev txuas tshwj xeeb thiab cov saw hlau ua liaj ua teb haum rau txhua qhov kev ua haujlwm hnyav. Lawv yog ua los ntawm cov hlau resistant alloysteel nrog anti-corrosioncoating thiab yog sib xws nrog kev cai K, F, CA attachments rau sau, tsheb laij teb thiab balers.High tensile zog rau lub neej kev pab cuam ntev, saj zawg zog OEM & ODM rau ntiaj teb no ua liaj ua teb machinery wholesalers.
Parameter
Feem ntau ntawm peb cov neeg siv khoom OEM xa peb daim duab thiab peb yuav tsim raws li lawv daim duab. Koj tuaj yeem xa peb cov duab kos los ntawm e-mail thiab ces peb tus engineer yuav muab kev pab. Yog tsis muaj duab kos, qauv kuj OK. Catalog kuj OK.
Drawings thiab cov ntaub ntawv parameter
Nqaij ntau lawm kab conveyor saw yog tsuas yog siv rau slaughtering, txiav, deboning thiab lwm yam ntau lawm kab ntawm cov tsiaj nyeg thiab nqaij qaib ua, thiab cov khoom mas muaj xws li P8o series, SJ ob lub pob khawm series thiab lwm yam chains.
Siv cov khoom zoo-cov ntaub ntawv zoo thiab kev ua haujlwm siab heev, cov khoom lag luam muaj cov yam ntxwv ntawm lub zog siab thiab corrosion kuj: Ob chav hinged saw tuaj yeem khiav kev ntseeg siab ntawm kab rov tav, ntsug thiab bi- cov lus qhia nkhaus conveying kab, thiab muaj cov yam ntxwv ntawm kev ruaj khov thiab kev saib xyuas yooj yim.
Conveyor saw nrog txuas
| Chain No. | Suab | Cov menyuam txoj kab uas hla |
Dav nruab nrab daim hlau sab hauv |
Pin txoj kab uas hla |
Pin ntev |
Sab hauv phaj qhov tob |
Phaj tuab |
Tensile zog |
Nruab nrab tensile zog |
Qhov hnyav rau meter |
| P | d1 max |
b1 min |
d2 max |
L max |
h2 max |
t/T max |
Q min |
Q0 | q | |
| mm | mm | mm | mm | mm | mm | mm | kN/lbf ib | kN kev | kg/m | |
| P78.11F10 | 78.105 | 31.75 | 38.1 | 16.46 | 102.0 | 44.45 | 12.7/9.5 | 333.4/75000 | 350.0 | 16.73 |
| P101.6F28 | 101.600 | 38.10 | 50.8 | 17.48 | 122.0 | 44.45 | 12.7 | 266.7/60000 | 293.3 | 21.66 |
| P152F18 | 152.400 | 69.85 | 76.2 | 25.40 | 152.0 | 63.50 | 12.7 | 500.0/112480 | 650.0 | 43.23 |
| P152F24 | 152.400 | 69.85 | 76.2 | 25.40 | 152.0 | 63.50 | 12.7 | 565.0/127100 | 650.0 | 38.38 |
| P152F248 | 152.400 | 69.85 | 76.2 | 25.40 | 151.4 | 69.85 | 12.7 | 431.5/59001 | 474.7 | 44.70 |
| Chain No. | Suab | Bush txoj kab uas hla |
Dav nruab nrab daim hlau sab hauv |
Pin txoj kab uas hla |
Pin ntev |
Sab hauv phaj qhov tob |
Phaj tuab |
Daim ntawv txuas qhov ntev |
Tensile zog |
Qhov hnyav rau meter |
||
| P | d1 max |
b1 min |
d2 max |
L max |
Lc max |
h2 max |
T max |
H | L1 | Q min |
q | |
| mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | kN/lbf ib | kg/m | |
| P100F49 | 100.0 | 20.0 | 25.0 | 14.0 | 51.5 | 55.0 | 35.0 | 5.0 | 30.0 | 28.0 | 90.0/20250 | 4.02 |
| P100F54 | 100.0 | 26.0 | 35.0 | 18.0 | 65.5 | 71.0 | 45.0 | 6.0 | 30.0 | 28.0 | 100.0/22500 | 6.90 |
Universal txav conveyor chains
| Chain No. | Suab | Dav nruab nrab daim hlau sab nrauv |
Pin txoj kab uas hla |
Pin ntev |
phaj qhov tob |
phaj tuab |
Daim ntawv txuas qhov ntev |
Tensile zog |
Nruab nrab tensile zog |
Qhov hnyav rau meter |
||
| P | b1 min |
d2 max |
L max |
Lc max |
h2 max |
T max |
F | d4 | Q min |
Q0 | q | |
| mm | mm | mm | mm | mm | mm | mm | mm | mm | kN/lbf ib | kN kev | kg/m | |
| SJ250F3 | 250.00 | 24.6 | 12.0 | 40.0 | 45.0 | 30.0 | 5.0 | 35.0 | 14.0 | 90/20230 | 94.0 | 4.41 |
| SJ250F4 | 250.00 | 31.0 | 16.0 | 48.0 | 53.0 | 35.0 | 6.0 | 35.0 | 18.0 | 150/33720 | 160.0 | 6.90 |
| SJ266.66 | 266.66 | 25.0 | 12.0 | 40.0 | 45.0 | 30.0 | 5.0 | 35.0 | 14.0 | 100/22480 | 105.0 | 4.28 |
| SJ 280 | 280.00 | 31.0 | 16.0 | - | 60.7 | 40.0 | 6.0 | 40.0 | 16.0 | 112/25177 | 117.6 | 7.00 |
| SJ300F3 | 300.00 | 24.6 | 12.0 | 40.0 | 45.0 | 30.0 | 5.0 | 35.0 | 14.0 | 90/20230 | 94.0 | 4.02 |
| SJ300F4 | 300.00 | 31.0 | 16.0 | 48.0 | 53.0 | 35.0 | 6.0 | 35.0 | 18.0 | 150/33720 | 160.0 | 6.22 |
| Chain No. | Suab | Cov menyuam txoj kab uas hla |
Dav nruab nrab daim hlau sab nrauv |
Pin txoj kab uas hla |
Pin ntev |
phaj qhov ntev |
Daim ntawv txuas qhov ntev |
Tensile zog |
||||
| P | d1 max |
b1 min |
d2 max |
d3 max |
L2 max |
L3 max |
Lc max |
h2 max |
T max |
F | Q min |
|
| mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | kN/lbf ib | |
| SJ240F1 | 120.0 | 16.0 | 18.6 | 10.0 | 12.0 | 28.0 | 25.9 | 27.5 | 22.0 | 2.5 | 22.0 | 30.0/6744 |
| Chain No. | Suab | Dav nruab nrab daim hlau sab nrauv |
Pin txoj kab uas hla |
Pin ntev |
phaj qhov ntev |
Daim ntawv txuas qhov ntev |
Tensile zog |
||||
| P | b1 min |
d2 max |
d3 max |
L max |
Lc max |
L1 max |
h2 max |
T max |
F | Q min |
|
| mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | kN/lbf ib | |
| SJ250 F6 | 90.0 | 31.0 | 14.0 | 14.0 | 46.5 | 50.5 | 130.0 | 35.0 | 5.0 | 35.0 | 100.0/22480 |
| SJ300F 9 | 115.0 | 31.0 | 16.0 | 18.0 | 48.0 | 53.0 | 130.0 | 35.0 | 6.0 | 35.0 | 125.0/28100 |
| Chain No. | Suab | Dav nruab nrab daim hlau sab nrauv |
Pin txoj kab uas hla |
Pin ntev |
phaj qhov ntev |
Daim ntawv txuas qhov ntev |
Tensile zog |
|||||||
| P | b1 min |
d2 max |
d3 max |
L max |
L3 max |
h2 max |
T max |
h3 | h4 | L1 | d4 | F | Q min |
|
| mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | kN/lbf ib | |
| SJ250F 9 | 90.0 | 25.0 | 12.0 | 14.0 | 45.0 | 130.0 | 30.0 | 5.0 | 55.0 | 72.0 | 35.0 | 10.0 | 35.0 | 90.0/20232 |
| SJ300F2 | 110.0 | 30.4 | 16.0 | 16.0 | 58.0 | 132.0 | 40.0 | 6.0 | 55.0 | 70.0 | 32.0 | 12.0 | 40.0 | 230.0/51704 |
| SJ300F13 | 115.0 | 31.0 | 16.0 | 18.0 | 53.0 | 155.0 | 35.0 | 6.0 | 33.0 | 52.5 | 30.0 | 13.0 | 35.0 | 150.0/33720 |
| Chain No. | Suab | Pin txoj kab uas hla |
Dav nruab nrab daim hlau sab nrauv |
Pin txoj kab uas hla |
Pin ntev |
phaj qhov ntev |
Daim ntawv txuas qhov ntev |
Tensile zog |
||||||
| P | d1 max |
d5 max |
b1 min |
d2 max |
d3 max |
L max |
L3 max |
h2 max |
T max |
h3 | d4 | F | Q min |
|
| mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | kN/lbf ib | |
| SJ250F11 | 90.0 | 60.0 | 76.0 | 25.0 | 12.0 | 14.0 | 45.0 | 138.0 | 30.0 | 5.0 | 35.0 | 10.0 | 35.0 | 90.0/20232 |
| Chain No. | Suab | Pin txoj kab uas hla |
Dav nruab nrab daim hlau sab nrauv |
Pin txoj kab uas hla |
Pin ntev |
phaj qhov ntev |
Daim ntawv txuas qhov ntev |
Tensile zog |
|||||
| P | d1 max |
d5 max |
b1 min |
d2 max |
d3 max |
L max |
Lc max |
L3 max |
h2 max |
T max |
F | Q min |
|
| mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | kN/lbf ib | |
| SJ250F 7 | 90.0 | 60.0 | 77.0 | 25.0 | 12.0 | 14.0 | - | 45.0 | 135.0 | 30.0 | 5.0 | 35.0 | 50.0/11240 |
| SJ300 F8 | 115.0 | 60.0 | 77.0 | 31.0 | 16.0 | 18.0 | 48.0 | 53.0 | 138.0 | 35.0 | 6.0 | 35.0 | 150.0/33720 |
FAQ
Q: Puas yuav cov saw hlau corrode los ntawm ntev - kev sib cuag nrog nqaij brine?
A: Stainless hlau zoo tiv taus corrosive kua.
Q: Cov saw hlau puas tuaj yeem tua kab mob rau cov nqaij rhiav kev huv?
A: Split pin qauv enables tag nrho disassembly tu.
Q: Koj puas yog tuam txhab lag luam lossis chaw tsim khoom?
A: Peb yog Hoobkas.
Q: Koj qhov zoo yog dab tsi?
A: 1. Chaw tsim tshuaj paus, tus nqi sib tw tshaj plaws thiab zoo.
2. Zoo meej technical engineers muab kev txhawb nqa zoo tshaj plaws rau koj.
3. OEM muaj.
4. Cov khoom lag luam nplua nuj thiab xa khoom sai.
